SPECIFICATIONS
Current Rating: 3 Amps
Withstanding Voltage: AC 500V
Insulation Resistance: 1000M ohms Min
Contact Resistance: 20milli ohms Max
Operation Temperature: -40°to+105°
Insrlator Material: Polyester(UL94V-0)
Standard: 6T
Contact Material: Brass
Contact Plating: Au or Sn over 40u" Ni
Mox.Processing Temp: 230°C for 30-60 seconds
(260° C for 5-10 seconds)
